Product specifications
Article codeHousingAir output max.Air pressure max.AirspeedAir temperature max.ConnectionAir consumptionFlangeNoise level DimensionsHose diameterWeight
SAV-serie SAV13 Anti-static Polyethylene 1470 m³/h @ 60psi
1835 m³/h @ 80psi
2047 m³/h @ 100psi 140psi/9.65 bar - -50°C to 100°C Claw coupling 1/2" NPT 51 m³/h @ 60psi
68 m³/h @ 80psi
85 m³/h @ 100psi API 3” (6.56” BC) - 425mm x 180mm Ø - 2kg
SAV20 SAV20 Anti-static Polyethylene 1928 m³/h @ 60psi
2225 m³/h @ 80psi
2489 m³/h @ 100psi 140psi/9.65 bar - -50°C to 100°C Claw coupling 1/2" NPT 51 m³/h @ 60psi
68 m³/h @ 80psi
85 m³/h @ 100psi API 3” (6.56” BC) - 800mm x 190mm Ø - 3kg
SAV30 SAV30 Anti-static Polyethylene “4349 m³/h @ 60psi“
“5131 m³/h @ 80psi“
“6286 m³/h @ 100psi“ 140psi/9.65 bar - -50°C to 100°C Claw coupling 1/2" NPT 102 m³/h @ 60psi
136 m³/h @ 80psi
170 m³/h @ 100psi API 6” (10.5” BC) - 1124mm x 320mm Ø - 6.8kg
SAV30-SA SAV30-SA Anti-static Polyethylene “4349 m³/h @ 60psi“
“5131 m³/h @ 80psi“
“6286 m³/h @ 100psi“ 140psi/9.65 bar - -50°C to 100°C Claw coupling 1/2" NPT 102 m³/h @ 60psi
136 m³/h @ 80psi
170 m³/h @ 100psi API 6" (10.5" BC) - 1124mm x 320mm Ø 300 mm 7kg
